Description
Key Features
-
High Power Output: Delivers 100W RMS per channel at 4 ohms, ensuring strong, distortion-free audio performance.
-
Compact Class D Design: Efficient and compact form factor allows easy installation in tight car spaces.
-
Versatile Tuning Options: Includes selectable high-pass and low-pass filters for better sound control.
-
Premium Build Quality: Engineered with high-grade internal components for reliable long-term use.
-
Advanced Protection Circuitry: Features thermal, overload, and short-circuit protection for added safety.
Technical Specifications
| Specification | Details |
|---|---|
| Amplifier Type | Class D |
| Channels | 4 |
| RMS Power @ 4Ω | 100W × 4 |
| RMS Power @ 2Ω | 150W × 4 |
| Bridged Power @ 4Ω | 300W × 2 |
| Frequency Response | 10Hz – 35kHz |
| Signal to Noise Ratio | >90dB |
| THD (Total Harmonic Distortion) | <0.05% |
| Crossover Type | HPF / LPF |
| Crossover Range | 50Hz – 500Hz |
| Input Type | RCA & High-Level Inputs |
| Dimensions (L×W×H) | Approx. 260mm × 160mm × 50mm |
| Protection | Overload, Short Circuit, Thermal |
