Description
Key Features
-
Compact 5‑Channel Class‑D Design: Delivers powerful, efficient amplification in a space-saving size—perfect for full-range setups.
-
Bridgeable Rear Channels: Allows configuration for subwoofer output while powering separate front and rear speakers.
-
Advanced Crossover Control: Equipped with adjustable high-pass and low-pass filters for precise tuning of all speaker outputs.
-
Thermal & Electrical Protection: Includes safeguarding against overheating, short circuits, overloads, and reverse polarity.
-
Remote Subwoofer Control Ready: Compatible with wired remote modules for real-time bass adjustment.
Technical Specifications
| Specification | Details |
|---|---|
| Channels | 5 (4 full-range + 1 subwoofer) |
| Output Power (RMS) | 50 W × 4 @ 4 Ω (front+rear) + 200 W × 1 @ 4 Ω (sub) |
| Output Power (RMS) | 75 W × 4 @ 2 Ω + 300 W × 1 @ 2 Ω |
| Peak Power | 500 W total |
| Frequency Response | 10 Hz – 50 kHz |
| Crossover Filters | HPF 50–500 Hz, LPF 50–250 Hz (sub); 12 dB/oct |
| THD + N | < 0.05% |
| Input Sensitivity | 200 mV – 6 V |
| Signal-to-Noise Ratio | > 90 dB |
| Remote Subwoofer Control | Optional wired remote module support |
| Dimensions (L×W×H) | 215 × 180 × 48 mm |
| Cooling System | Efficient heat sink, thermal protection |
| Protection Circuitry | Overheat, short circuit, overload, DC polarity |
