Description
Key Features
-
High Power Output: Delivers 200W RMS x 4 @ 4Ω and 300W RMS x 4 @ 2Ω, suitable for both speakers and small subwoofers.
-
Bridgeable Configuration: Supports 4Ω bridged output at 300W x 2 for subwoofer applications.
-
Advanced Crossover Options: Offers HPF, LPF, Bandpass & Full range filter settings for precise tuning.
-
Compact Yet Durable Build: Features a compact Class-D chassis with heat management and protection circuitry for long-term use.
-
Direct Connect Terminals: Includes high-quality terminals for easy and secure installation with 4-gauge wiring support.
Technical Specifications
| Specification | Details |
|---|---|
| Channel Configuration | 4-Channel Class-D |
| RMS @ 4Ω | 200W x 4 |
| RMS @ 2Ω | 300W x 4 |
| RMS Bridged @ 4Ω | 300W x 2 |
| Frequency Response | 20Hz – 22kHz |
| Signal-to-Noise Ratio | > 105dB |
| Crossover Modes | HPF / LPF / Bandpass / Full |
| HPF Range | 20Hz – 5kHz |
| LPF Range | 50Hz – 5kHz |
| Bass Boost | 0 – 9dB |
| Input Sensitivity | 0.2V – 6V |
| Thermal Protection | Yes (APC, CHM, SESI) |
| Power Input | 4-Gauge |
| Dimensions (L×W×H) | 228.6mm × 139.7mm × 60.5mm |
