Description
Key Features:
- Seamless Smartphone Integration: The XAV-AX5500 supports Apple CarPlay and Android Auto via USB connection, allowing you to access navigation, music, calls, and messages through the touchscreen or voice control.
- WebLink™ Cast Support: Mirror your smartphone screen onto the receiver using WebLink™ Cast. Enjoy supported apps like YouTube, navigation, and more on the large display.
- Anti-Glare Bezel-less Display: Features a 17.6 cm (6.95″) capacitive touchscreen with anti-glare finish and a flush bezel-less design for a sleek, modern in-dash look and intuitive operation.
- Built-in Bluetooth®: Connect your smartphone wirelessly for hands-free calling and high-quality music streaming. Quick and stable pairing for daily use.
- Dynamic Sound with Extra Bass: Powered by a built-in 4 × 55 W Dynamic Reality Amp 2, this receiver delivers punchy, clear audio with support for Extra Bass and DSO (Dynamic Stage Organizer).
- Expandable & Camera Ready: Comes with 3 pre-outs (5V) to connect amplifiers and subwoofers. Rear camera input with customizable parking guidelines enhances safety while reversing.
—
Technical Specifications:
| Feature | Description |
|---|---|
| Product Type | Digital Media Receiver |
| Model Code | XAV-AX5500 |
| Display Size | 17.6 cm (6.95″) |
| Display Type | Capacitive, Anti-Glare, Bezel-less |
| Smartphone Integration | Apple CarPlay & Android Auto (USB) |
| Screen Mirroring | WebLink™ Cast |
| Built-in Amplifier | 4 × 55 W Dynamic Reality Amp 2 |
| Bluetooth® | Yes – Hands-Free & A2DP Streaming |
| Audio Tuning | 10-Band EQ, Extra Bass, DSO |
| Outputs | 3 Pre-Outs (5V: Front / Rear / Subwoofer) |
| Inputs | USB-A, Rear Camera Input |
| Chassis Type | Double-DIN |
| Camera Support | Yes, with Parking Guide Lines |
