Description
Key Features:
- Stunning Floating Display: Features a large 10.1″ anti-glare capacitive touchscreen (1280 × 720 HD resolution) mounted on a flexible single-DIN chassis. Offers tilt, height, and depth adjustments to match a wide range of dashboards and viewing angles.
- Wireless Apple CarPlay & Android Auto: Enjoy seamless connectivity to your smartphone without cables. Access calls, navigation, music, and voice assistants wirelessly, or connect via USB for faster charging and stable operation.
- HDMI & USB-C Connectivity: Rear HDMI input supports video sources, while USB-C delivers high-speed charging and fast media access. Also includes a rear USB-A port for flexible device compatibility.
- Customizable Audio Experience: Equipped with a 14-band graphic EQ, 3-zone crossover, time alignment, and 5V pre-outs (Front/Rear/Sub) for audiophile-level tuning and amplifier integration.
- Triple Camera Support: Comes with three camera inputs, each with independent triggers—ideal for rear, front, or side cameras. Great for safer parking and maneuvering.
- Compact 1-DIN Installation: The slim main unit fits into standard 1-DIN slots, while the large display gives the aesthetic and functionality of a full multimedia center.
—
Technical Specifications:
| Feature | Description |
|---|---|
| Product Type | Digital Media Receiver |
| Model Code | XAV-AX8500 |
| Display | 10.1″ Floating HD (1280 × 720), Anti-Glare |
| Touchscreen Type | Capacitive |
| Amplifier | Built-in 4 × 55 W Dynamic Reality Amp |
| Smartphone Support | Apple CarPlay & Android Auto (Wireless & Wired) |
| Audio Features | 14-Band EQ, 3-Zone Crossover, Time Alignment |
| Outputs | 5V Pre-Outs: Front / Rear / Subwoofer |
| Inputs | HDMI, USB-C, USB-A, 3 Camera Inputs |
| Camera Support | Rear / Side / Front with Separate Trigger Lines |
| Chassis | 1-DIN Body with Adjustable Floating Display |
| Installation | Tilt, Height, and Depth Adjustable |
| Bluetooth | Yes – for Streaming and Hands-Free Calling |
